Bezzera Unica V2 Semi-Automatic PID Espresso Machine

Overview:

Newest sexy and sleek addition to 1st-line Equipment. Classic lever design. E61 grouphead. Polished stainless steel body. Thermosyphon tube system. Single boiler, dual purpose boiler regulated with a PID. Three liter water tank. Vibration pump. NSF approved Nistla (nickel) plated copper boiler. For those who cherish the best in an espresso only beverage, the Bezzera Unica is one of the top contenders for your use!

Features:

  • Single boiler machine: Handles both espresso extractions and steaming functions. To get to steam mode, the steam switch needs to be depressed.
  • PID temperature control: Manages the coffee and steam temperature set by the user.
    • The coffee temperature can be programmed between 80 C – 100 C.
    • The steam temperature can be programmed between 105 C – 120 C.
  • Stainless steel body: Polished to a mirror finish.
  • E61 grouphead: Hot water circulates from thermosyphon tubes to / from the grouphead and boiler. The purpose is to keep the grouphead and your portafilter nice and hot. This is dual purpose, single boiler machine that does not have a heat exchanger. Lever next to the grouphead activates a microswitch which turns on the pump to pump water through the coffee grinds.
  • Pump pressure gauge: Indicate brew pressure during espresso extraction. Below pump pressure gauge, there is a ‘P’ switch that powers on the pump for hot water delivery through the opened steam wand. The ‘O/I’ switch is for powering up the espresso machine. The light in between is the power light.
  • Multi-directional steam wand: Allows for more flexibility. Joystick controls for steam wand gives instant on / off operation as opposed to knobs that you must turn clockwise/counter clockwise. Control locks to full open in the up position allowing you to use both hands when steaming..
  • Powerful vibratory pump: Rated at 15 bar. Please note that only 9 bar is needed for espresso.
  • Three way solenoid valve: Allows quick removal of portafilter after espresso extraction and immediately prepare for the next extraction.
  • Over pressure valve (OPV): Adjustable.
  • Water tank: Very large and removable.
  • Passive cup warmer on the top: Heat from the boiler rises and heats the top panel. Like any other espresso machine, it can take up to two hours to preheat your cups. Therefore, it is better to flash heat the cups from hot water from the grouphead or steam/water wand.
  • Accessories included: Single spout portafilter, double spout portafilter, 1-cup filter basket, 2-cup filter basket, blind filter basket, plastic tamper, plastic scoop, grouphead cleaning brush, instruction manual.

For more Bezzera products, please visit our Bezzera brands page. If you have any questions, please reference the Q&A tab on each product page.
Brand

Bezzera

Height (inches)

15, approximate

Width (inches)

10, approximate

Depth (inches)

17, approximate

Weight (pounds)

41

Wattage (watts)

1300

Voltage (volts)

110

Boiler capacity (liters)

0.5

Portafilter size (mm)

58

Tank capacity (liters)

3

Country of manufacture

Milan, Italy

Approvals

CE

Espresso Machine Warning:

  • ELECTRICAL WARNING: To avoid electrical damage to this espresso machine which is not considered a manufacturer's defect, please acquire and install a single-outlet surge suppressor rated at 1080 joules or higher. the lack of the recommended surge suppressor, the espresso machine can be damaged at the power switch, the electronics, the heating element, the pressurstat or the wiring inside.
  • WATER WARNING: To increase the useful life of and not damage your espresso machine, please use softened water. Softened water is water without calcium and without magnesium, but still has other minerals for espresso extraction. Do not use distilled water, purified water, nor reverse osmosis water as these types of water create oxidation with the metals and cause the same damaging effects as limescale.
  • DESCALING WARNING: We do not recommend descaling unless there is an issue with the espresso machine. The reason is that too much descaling can eat away at the metals and gaskets inside an espresso machine.

  1. Warning: Failure to fill the boiler with water or keep it filled with water (running boiler dry) can result in damage to the heating element for which the manufacturer will not accept responsibility. Therefore, upon first use of the machine, it is imperative to immediately run water through the steam wand. the same should be performed after steaming session of 20 or more ounces of milk as steaming milk will lower the water level in the boiler.

Please use the diagrams below to help find the exact part you are looking for. After you find the part, copy the SKU #. Then use the search bar at the top of our website. If there are no results in the search, we most likely do not have the part. We only special order parts if the specific model was purchased through 1st-line Equipment. For general questions, please use our parts inquiry page.

TAB. 1 (up to 30.11.15)

Bezzera-Unica-parts-diagram-03
# SKU
1 5964627.01
2 5071733LL
3 5340510
4 5963068.03
5 5074476.01SG
6 7373009
7 5074621LW
8 5074634LW
9 7474217
10 5373102.01
11 5073020LW
12 7816002
13 7816004
14 5220818
15 7817004
16 7474218
17 7611517
18 5125705

TAB. 1 (from 01.12.15)

Bezzera-Unica-parts-diagram-05
# SKU
1 5964627.01
2 5071733LL
3 5340510
4 5963068.03
5 5074476.01SG
6 7373009
7 5074621LW
8 5074634LW
9 7474217
10 5373102.01
11 5073020LW
12 7816002
13 7816004
16 7474218
17 7611517
18 5125705
19 5521512

TAB. 2 (up to 30.10.12)

Bezzera-Unica-parts-diagram-07
# SKU
1 5283049
2 5224615TP
3 5302017TP
4 5493001
5 5224619TP
6 5302072
7 5471505
8 5471506.01
9 7496018
10 5194549
11 7303033
12 5194555
13 5194562
14 5225411TP
15 7304502TR
16 7452512
17 5162296LL
18 5194589LL
19 7496052
20 7304507TR
21 7496085
22 5965165

TAB. 2 (up to 26.02.14)

Bezzera-Unica-parts-diagram-09
# SKU
1 5283053TP
2 5224615TP
3 5302017TP
4 5493042
5 5224620TP
6 5302077TP
7 5471505
8 5471539
9 7496018
10 5194549
11 7303033
12 5194591
13 5194562
14 5225411TP
15 7304502TR
16 7452512
17 5162296LL
18 5194589LL
19 7496052
20 7304507TR
21 7496085
22 5965212AL

TAB. 2 (from 27.02.14)

Bezzera-Unica-parts-diagram-11
# SKU
1 5283053TP
2 5224615TP
3 5302017TP
4 5493042
5 5224620TP
6 5302077TP
7 5471505
8 5471539
9 7496018
10 5194562
11 7303033
12 5194591
13 5194610
14 5225411TP
15 7304502TR
16 7452512
17 5162296LL
18 5194589LL
19 7496052
20 7304507TR
21 7496085
22 5965212AL
23 7303006

TAB. 3 (up to 28.01.14)

Bezzera-Unica-parts-diagram-13
# SKU
1 5964085AL
2 5225410TP
3 5224603TP
4 5496042
5 5283047TW
6 5221826CM
7 5494004
8 5261801
9 5471513
10 5260204DL
11 5225610
12 5222823CM
13 7371511.01
14 7479990TW
15 7496073
16 5221872TW
17 7371003
18 7496084
19 7305014
20 7496072
21 5471532
22 5190501

TAB. 3 (from 29.01.14 to 08.06.17)

Bezzera-Unica-parts-diagram-15
# SKU
1 5964085.01AL
2 5225416TP
3 5224603TP
4 5496042
5 5283055TW
6 5221826CM
7 5494004
8 5261801
9 5471513
10 5260204DL
11 5225610
12 5222823CM
13 7371511.01
14 7479990TW
15 7496073
16 5221872TW
17 7371003
18 7496084
19 7305014
20 7496072
21 5471532
22 5190501
23 7496052

TAB. 3 (from 09.06.17)

Bezzera-Unica-parts-diagram-17
# SKU
1 5964085.01AL
2 5225416TP
3 5224603TP
4 5496042
5 5283055TW
6 5221826CM
7 5494004
8 5261801
9 5471513
10 5260204DL
11 5225610
12 5222823CM
13 7371511.01
14 7479990.02TW
15 7496073
16 5221872TW
17 7371004
18 7496095
19 7305019
20 7496072
21 5471532
22 5190501
23 7496052

TAB. 4

Bezzera-Unica-parts-diagram-19
# SKU
1 7432523
2 5225410TP (up to 28.01.14)
5225416TP (with o-ring, from 29.01.14)
3 5162297LL
4 5221844
5 7304509TR
6 7400902
7 7634814
8 5302067
9 7666002
10 5320519BL
11 5037831.01LL
12 5227002
13 7816002
14 5721133TP (110V)
5722309TP (220/240V)
15 5494016
16 5162296LL
17 5164080LL
18 5164079LL

TAB. 5

Bezzera-Unica-parts-diagram-21
# SKU
1 7479952
2 7479953
3 7479954
4 7479955
5 7479956
6 7479933
7 7479934
8 7479935
9 7479936
10 7479937
11 7479940
12 7493011
13 5267013
14 7812607
15 7479938
16 7479939
17 7479951
18 7479950
19 7479949
20 7371511.01
21 7479931
22 7479947
23 7479948
24 7479946
25 7479942
26 7479957
27 7479943
28 7479944
29 7479945
30 7479960
31 7479961
32 7479941
33 5471022
34 5493039
35 7479967
36 7479968
37 7479969
38 7479970
39 7479971

TAB. 6

Bezzera-Unica-parts-diagram-23
# SKU
1 5194631.01R (up to 13.12.15)
5194639 (from 14.12.15)
2 7611516
3 7303006
4 5194582
5 7731018 (100V)
7731022 (220V)
7731020 (230V)
7731019 (120V)
7731021 (240V)
6 7470602
7 7303042TR
8 7805009
9 7816002
10 7374015
11 5194582R
12 7634816
13 5225418TP
14 7496018

TAB. 7

Bezzera-Unica-parts-diagram-25
# SKU
1 5522074
2 7374016
3 7434019 (110V)
7434018 (230/240V)
4 5058405LL
5 5191508
6 5222204
7 5053025LW
8 7816002
9 7819911
10 7633907
11 7633906
12 7635424.01
13 7614007
14 7614006
15 7551001 (USA, 125V, 15A)
7551003 (USA, 250V, 20A)
7554001 (English)
7555001 (Schuko)
7552001 (Australian)
7555003 (Switzerland)
7553001 (Israel)
16 5221875CM
17 7633326
18 7372507
19 7633626
20 5191509

TAB. 8

Bezzera-Unica-parts-diagram-27
# SKU
1 7990603
2 5373001
3 5471035
4 5471031.01
5 5965611R
6 5471527
7 7479972.01TW
8 7305007TW
9 7371502
10 5373915CM
11 7305006TW
12 5965610R
13 5471003
14 5372101

Customer reviews

Rated 5 out of 5 stars
2 reviews
4 stars 0 0 %
3 stars 0 0 %
2 stars 0 0 %
1 star 0 0 %

2 reviews for Bezzera Unica V2 Semi-Automatic PID Espresso Machine

Add a review

Use one of the allowed file type: jpg,png. The max size allowed is : 3 MB.

    This site uses Akismet to reduce spam. Learn how your comment data is processed.

    Please ask follow up questions as a new question. Submitted questions will be first reviewed, answered, and lastly publicized.

    1. 0 votes
      Q I'm looking for replacement boiler for my unica pid. answer now
      Asked by ido on November 16, 2020 5:29 pm
      Answered by the admin

      We do have one replacement boiler in stock.

    2. 0 votes
      Answered by the admin

      It can take up to 8 seconds to get p to full pressure. The coffee grinds absorbs coffee, as well. The swelling of the coffee and inconsistent grind usually creates the issue you are experiencing.

      If you like, the machine can be dropped off for service. Sorry, our roadside techs only work on commercial machines, and we are sorry that they do not want to be responsible for damages to a machine they need transport. We also do not ship machines dropped off for service because it will damaged on the return because we do not have the original packaging. Some clients do use ZipCar.

    3. 0 votes
      Answered by the admin

      If the blind filter does not replicate the same issue, this issue clearly points to the grind fineness and/or grinder. The blind filter tells us

      a) the pump can achieve 10 bar,

      b) the OPV opens at 10 bar,

      c) the system has no leaks as it maintains 10 bars.

      Hence, the machine is fine. We would feel that we would be cheating you if we had to service the machine and found nothing wrong.

    4. 0 votes
      Answered by the admin

      "With the blind filter basket in, the brew pressure is steady at about 10 bar. There is no brew pressure bouncing up and down. Just holding nicely at about 10 bar."

      The blind test tells us that the machine is operating normally. If there was an issue with the machine, it would show up with the blind filter test because this is when the machine is stressed under maximum pressure.

      The issue is now pointing to the grinder, the amount of coffee in the basket, or the tamp. Most likely, the issue is the grinder - bad burrs causing inconsistent grind quality. we have seen some cases where the electrical current in the outlet caused the same issue.
