Description

VBM Domobar Super HX Vibration Pump Tank Espresso Machine

Overview:

Sold at 1st-line since 2006, this particular model has consistently outperformed many competitive models (sold by us and not sold by us) in terms of reliability and performance. With the least defects on a percentage of machines sold, we knew at that time there were several reasons for this!

In fact, other manufacturers started to utilize a similar restrictor in the thermosyphon tubes (2 tubes running from grouphead to boiler) to better regulate overheating of their E61 groupheads. VBM did this from the start to enhanced their espresso extraction performance!

VBM still uses 10mm inside diameter/12mm outside diameter thermosyphon tubes, whereas most other manufacturers are using smaller tubes (which tend to create greater overheating of the grouphead). Also, more metal means more cost here. Less metal means less cost for a manufacturer. No skimping by VBM!

Another reason for reliability is the position of the electronics. Down in the bottom rear of the machine – away from the heat of the boiler! Couple the large boiler with high output steam wands, and this machine froths milk in a jiffy. In fact, VBM has refused to place the so-called no-burn steam wands for 2 reasons: they slow down performance to froth milk AND they have silicone inside the pipe which sometimes tends to create foul odors.

VBM has the most robust grouphead in the industry. Hands down. Customers who see these E61 espresso machines in person tend to gravitate towards the VBM grouphead due to its robustness and structure.

All in all, the high quality construction makes the next step up a commercial machine. ALL STAINLESS BODY AND CHASSIS – NO BLACK ENAMEL PAINTED FRAME THAT CAN CHIP OR RUST! If you can fit this machine in your home and office, you will not regret purchasing this unit! We don’t as we use the VBM Super HX machines for catering events up to 250 people! Now, that’s performance!

Features particular to the VBM Domobar Super Manual Stainless

  • Gorgeous polished stainless steel body panels.
  • Small lever on side of grouphead allows user to engage/disengage pump and three-way manual solenoid valve to start/stop espresso extraction.
  • Manual three way valve below grouphead allows removal of portafilter handle from grouphead immediately after espresso extraction has terminated.
  • Insulation on inner wall between water reservoir and internal boiler.
  • The electronic brain unit is located on the bottom rear – away from heat that rises from a hot boiler and that can damage electronics.
  • Easy self-repairable (some skill needed) as this machine is one of the easiest to diagnose and self-repair (saves on shipping!)

Common features across all VBM Domobar Super Espresso Machines

  • Heavy duty VBM ‘true’ E61 grouphead maintains active flow of water from the grouphead to the heat exchanger in the boiler.
  • The heat exchanger allows you to make espresso after espresso until water reservoir is emptied – plus with the larger boiler, you can steam milk at the same time.
  • Professional grade brass portafilters – one portafilter with single spout and single filter basket and one portafilter with dual spout and double filter basket.
  • Boiler pressure gauge to indicate boiler pressure (reading will vary between .8 and 1.2 bar pressure). The setting can be varied by adjusting the full size pressure-stat through the access port under the cup warmer tray on top of machine.
  • Pump pressure gauge to indicate brew pressure during espresso extraction (reading will vary while not extracting – this is normal).
  • Multi-directional stainless steel steam wand on left side can be moved in different directions.
  • Multi-directional stainless steel hot water tap on right side can be moved in different directions.
  • Power indicator light on right side indicates when the machine is powered on.
  • Heating light on left side indicates when espresso machine is heating.
  • Low water level light in middle indicates when water level in water reservoir in rear is low.
  • Three stage power switch allows user to fill internal boiler without sending power to the heating element (prevents damage upon initial start up).
  • Full size pressure-stat (rated as one of the best boiler pressure regulators) monitors boiler pressure.
  • Extremely large stainless steel drip tray which can be easily (slides out with pull of handle) removed for cleaning. Grate stays on machine when pulling out drip tray so that it is one step to empty.
  • GICAR branded electronic water level control for internal boiler is located in lower right rear corner of machine where there is least heat build up.
  • 41 watt vibratory pump (“vibe” pump) rated up to 15 bar with air valve bypass – please note that only 9 bar is needed to make espresso. Do not be fooled for machines with higher pump pressure as one is only creating too much UN-needed pressure on the internal system.
  • Largest OPV (over pressure valve opens when too much pump pressure exists) located in rear of machine with easy access when body panel and six (6) associated screws are removed.
  • Accessories: Single spout portafilter, single dose filter basket, double spout portafilter, double dose filter basket, blind filter basket for backflushing, plastic coffee scoop, and a common useless plastic tamper (please make sure to order a good tamper).

Additional information

Brand

VBM (Vibiemme)

Height (inches)

16.5, approximate

Width (inches)

11, approximate

Depth (inches)

20, approximate

Weight (pounds)

70

Wattage (watts)

1600

Voltage (volts)

110

Boiler capacity (liters)

1.8

Portafilter size (mm)

58

Tank capacity (liters)

2.1

Country of manufacture

Milan, Italy

Approvals

UL

Espresso Machine Warning:

  • ELECTRICAL WARNING: To avoid electrical damage to this espresso machine which is not considered a manufacturer's defect, please acquire and install a single-outlet surge suppressor rated at 1080 joules or higher. the lack of the recommended surge suppressor, the espresso machine can be damaged at the power switch, the electronics, the heating element, the pressurstat or the wiring inside.
  • WATER WARNING: To increase the useful life of and not damage your espresso machine, please use softened water. Softened water is water without calcium and without magnesium, but still has other minerals for espresso extraction. Do not use distilled water, purified water, nor reverse osmosis water as these types of water create oxidation with the metals and cause the same damaging effects as limescale.
  • DESCALING WARNING: We do not recommend descaling unless there is an issue with the espresso machine. The reason is that too much descaling can eat away at the metals and gaskets inside an espresso machine.

  1. No burn wands: We have decided to NOT offer no-burn steam wands because the typical internal diameter is about 50% less than a normal steam wand, and this usually affects performance times in steaming. In addition, the grouphead has a much greater area to get burned.
  2. Some assembly required: Feet are not attached to the machine.
  3. 220 volt: Sorry, 220-240 volt units are not available for ordering.
  4. Service notes:
    1. Backflushing: This machine should be backflushed minimum once every 50 espresso extractions using Ascaso Detergent (our instructions included with purchase). This is only for cleaning the oils from the grouphead.
    2. Water Usage: We prefer one uses softened (not just filtered) water to prevent limescale build up. Descaling really is for internally cleaning of the machine.

Maintenance

Documentation

Common Parts

Technical Support

Warranty Information

Who handles the warranty

Eligible warranty for Vibiemme home equipment is handled by 1st-line Equipment or representative thereof. If you have purchased your Vibiemme equipment from another retailer (not 1st-line Equipment), you must contact them first in order to get your equipment serviced under warranty.

What does the warranty cover

The warranty is limited to manufacturer’s defects only.

Regarding espresso machines: Limescale buildup can lead to problems with your machine. The warranty will not cover any repairs if our technicians find limescale in your machine. Although descaling can be a good alternative to remove limescale causing minerals (calcium and magnesium), we strongly suggest that prevention is the best form of maintenance. The reason is that descalers can cause wear and tear on components inside an espresso machine. This includes gaskets, o-rings, and other metal components. However, where there is a clog somewhere, descaling will be a necessity on the specified part, area, or entire machine.

Regarding coffee grinders: As with all coffee grinders, it is very important to only change grind settings when the unit is powered on and the burrs are in motion. If you do not do this, the burrs will ‘gunk’ up and require cleaning by you every time this occurs. Changing the grind settings when the burrs are not in motion will render the grinder to only produce very coarse grinds or no grinds at all. If this result occurs, this will be considered operator error for lack of following directions, and not be classified as a defective grinder.

When does the warranty expire

The manufacturer’s warranty on new equipment is good for a period of 1 year from date of receipt which covers parts. Labor warranties may vary depending on the company you purchase from. Vibiemme products may have an extended warranty limited to manufacturer’s defect and will specifically state the extended period of time on your receipt.

Where will my equipment be serviced

In most cases, your Vibiemme equipment must be sent to a repair facility. If 1st-line Equipment will be servicing your equipment, you must either ship it or drop off at our facility in New Jersey.

How do I send in my equipment in for repair

If you are inside the warranty period and have purchased it from us, please contact us. Please be ready to provide the following information: invoice# of purchase, model of equipment, and a detailed description of the issue.

If you are outside the warranty period, whether you have purchased the equipment from us or not, please order a diagnosis. Please note that wait times can be up to 8 weeks. Our technical support staff can have a back log of repairs. As an alternative we have a listing of 3rd party repair companies across the USA that can assist you.

Customer reviews

Rated 5 out of 5 stars
4 reviews
4 stars 0 0 %
3 stars 0 0 %
2 stars 0 0 %
1 star 0 0 %

4 reviews for VBM Domobar Super HX Vibration Pump Tank Espresso Machine

    Add a review

    Use one of the allowed file type: jpg,png. The max size allowed is : 3 MB.

      This site uses Akismet to reduce spam. Learn how your comment data is processed.

      Please ask follow up questions as a new question. Submitted questions will be first reviewed, answered, and lastly publicized.

      1. 0 votes
        Answered by the admin Correct is what the pressurstat states.
      2. 0 votes
        Answered by the admin The machine should be cold. Start with the steam tip and make sure holes are clean. Next remove the pipe and make sure it is clear. Unwind the knob all the way out, then while holding the valve body, loosen the nut nearest to the knob. If the entire valve spins, the copper tube behind the valve will spin and damage! Once the entire knob assembly is removed, check the end cap gasket. It is stuck inside. If not, then you have a blocakge in the copper steam pipe inside the machine which would need to be cleared. Otherwise, you machine is not producing steam.
      3. 0 votes
        Answered by the admin

        Sounds like a grinder or preparation issue. Use a blind filter and test the same way. If the blind filter shows consistency, then we know it is not the machine. Remember, HX machines need a cooling flush to get out the steam built up in the heat exchange tubes.

      4. 0 votes
        Answered by the admin

        With machine cold, remove the top nut on the grouphead. Inside there is an orifice (nut with a single hole) that is removed with a 7mm socket wrench. Once removed, descale the orifice and make sure the pin hole is clear. To put back, tighten gently with a socket and then only 1/8th turn to tighten. If you over tighten, there is a high chance the entire grouphead needs to be replaced. Reassemble and test.

      5. 0 votes
        Answered by the admin

        Sorry, there may be compounding issues here beyond the scope of our free service. Problem areas: limescale in machine, vacuum breaker valve sticking, loose or bad wire, brain unit starting to become defective, or bad indicator lights.

      6. 0 votes
        Answered by the admin Reverse osmosis water is not good for espresso machines because it causes oxidation and the refill sensor may not operate correctly.
      7. 0 votes
        Answered by the admin

        The wires under the reservoir need to be checked, and the pump wires need to be checked.

      8. 0 votes
        Answered by the admin

        4 ounces of hot water should be removed from the water wand every day. Milk can siphon back to the boiler after steaming on any espresso machine.

        Steam will always look clean because the steam exits from the top of the boiler, and hot water exits from the bottom of the boiler where the contamination lands.

        The water for the grouphead comes from a separate pipe that runs through the boiler on this heat exchanger espresso machine.

      9. 0 votes
        Answered by the admin

        Please purchase a SCACE device to properly diagnose temperature. Sorry, Instaread thermometers capture ambient temperature and there is no restriction of water flow when tested in this fashion. Unfortunately, without a SCACE device, increased water flow increases the drop in temperature. Without the SCACE, we have seen temperature drops as low as 160 d F.

      10. 0 votes
        Answered by the admin

        Sorry, what is a pd? The machine did not come with any accessories for double espresso pods, unless you were using one of the baskets that came with the machine.

      11. 0 votes
        Answered by the admin

        Please unplug the machine from the outlet and let the machine fully cool.

        Remove the top cover and reservoir, remove the 3 screws on each side of the body panel, remove the 2 screws found on the top and bottom of the reservoir platform. Remove the tank spring platform. Take pictures of the 3 wires on the switch under the reservoir. Loosen the nut on top of the reservoir platform holding the switch. Usually 2-3 revolutions. Tighten the nut under neath closest to the platform.

        Re-assemble. Test. Repeat if necessary. The tank should shut off with a minimum water level of 25%. The reason is that if there is an optional water softener attached, the pump can suck in air and other damage can occur.

      12. 0 votes
        Answered by the admin

        Please find the correct diagram. After finding the switch, please search it on our web site and then match the description and picture of the part you need.

        Sorry, we can not offer a direct link because there can be one of three switches under the platform over the years. The above procedure will help you order the correct switch.



      13. 0 votes
        Answered by the admin

        Thanks for the inquiry. Although great to hear that your machine has had some great use, we are sorry to hear about the current issue. First, as the call center advised, technical support inquiries for equipment outside of warranty need to be asked here as a machine purchase years ago, nor a parts purchase, can no longer support a technician on staff today, We also want to build a knowledge base because today's issues may happen tomorrow or in the future.

        Second, as far as your issue, do you really mean the power switch in position 2? The lever on the group is not numbered. If the power switch, yes there can be a delay or even normal is no pump action at all. It all depends how much water your boiler lost when it cooled down.

        If you are referring to the lever on the grouphead, then there should be no delay on the pump. This can be a pump, brain unit, or lever switch issue. A mulimeter would be needed. However, considering the age of the machine, a professional may be needed to evaluate it. The brain would need to be replaced to see if it was the brain.

        When referring to the brew pressure changes, this is usually a coffee grinder issue on a newer machine. On an older espresso machine, it can be the coffee grind, the pump, or the OPV. To test the pump, put a blind filter in the portafilter and see if it goes to 8-9 bar. If it does not, then there is prolly an issue with the pump as long as no water is coming out of the OPV. If the OPV has water coming out before 8-9 bar, then it may be leaking.

        As you can see, you may have compounded issues, and this is why we recommend a service professional to evaluate the machine.

      14. 0 votes
        Answered by the admin


        (1) The Brew Pressure gauge shows the result of the grind in your puck and the OPV seems to be set at 12.5. The pressurstat needs to be adjusted for the steam as it is too high.

        (2) Normal on some years.

        (3) The brew pressure should only be read during extraction. Outside f extraction, it should not go past 12 br. This means you have underlying issues from too much scale, a damaged heating element, or a damaged pressurstat. The machine should be evaluated by a professional when this many potential issues.

        4) Part number F15 and F277 should be puchased on our web site


        I guess the group head would need to be rebuilt?? I would like to know if you can suggest a parts "package" with all of the typical parts needed for this?

        ***Please use the appropriate diagram under the parts link on the top of our web site.

      15. 0 votes
        Answered by the admin

        The coil's resistance should be in an acceptable range of 8 to 16 ohms. We have seen some operate correctly as low as 6 ohms and high as 20 ohms.

        For the part, it is always best to check the Vibiemme parts diagram, back out to a page with a search field, and then search by part number on the diagram. Please note we try to update our diagrams when the manufacturers alert us, but sometimes they do not alert us in a change of the part (look, description, or picture), the part numbers, or other stuff. Hence it is best to look at the pictures of the part on our web site to confirm it is exactly what is in your machine. For example, sometimes a manufacturer may change the posts of the heating element and not say anything.

        It is best to use a socket wrench with an extension to remove the heating element.

      16. 0 votes
        Answered by the admin

        Inside the top nut (mushroom) on top of the grouphead, there is a gicleur (with a pinhole) that is probably clogged and needs clearance. Witht he machine cold, remove the mushroom and check inside for the gliclear (usually 8mm socket wrench with extension bar needed to remove) for deep descaling and cleaning.

      17. 0 votes
        Q I need a heating element for this machine. Do you have one in stock? answer now
        Asked by Caroline Flynn on September 12, 2018 3:23 pm
        Answered by the admin

        Here is a link to the correct heating element: ELETRESSM1811

      18. 0 votes
        Answered by the admin

        We are sorry to hear this. The problem could be bad wiring, a bad heating element, a bad power switch, a bad brain unit, or a bad safety thermostat. Most of these parts (exception brain unit) will need to be checked with a multi-meter for continuity without the wires connected. Of course, the machine needs to be unplugged from the electrical power outlet before any testing.

      19. 0 votes
        Answered by the admin

        Unplug the machine. Check your water level. Check the switch under the water tank platform for any burned wires. Press down on the platform for the reservoir and listen for the click of the switch. Check wires by heating element and throughout the machine for any burned wires.

        If you know how to use a multimeter, check the ohms on the heating element with the wires unplugged. It should be between 8 and 20. If you are very experienced and assume all responsibility for any and all damages as well as personal injury to any person, you can check voltage to the element. If you do not have knowledge on how to do this, we advise to never check voltage.

        Other than this, the board or power switch may need to be replaced. Sorry, these are more complicated procedures and out of the scope of our good will and free support.

      20. 0 votes
        Answered by the admin

        Thanks for letting us know how long your Vibiemme espresso machine is lasting. We always see very good track records with the Super HX models.

        As for your issue, there may be scale build up at the hot water valve pipe connection at the boiler. With the machine unplugged from the outlet and the water reservoir removed, take off the 6 screws to remove the body, then tilt the machine so the left side (facing front) is laying down on a towel.

        Follow the pipe from the hot water valve, and loosen the holding nut at the boiler. Then with a crescent wrench holding the outside of the valve by the knob, loosen the inner pipe connection on the inside wall of the valve. Do hot allow the pipe to twist. Inspect the pipe for clear pass through. Next check the inside of the boiler through the open port hole - changes you have some crud or limescale that needs to be cleared.

        At this point, you 'can' pour some descaling solution into the boiler through the port hole and re-connect the pipe in reverse of removal. Check for leaks. We would suggest removing the tip on the hot water wand when descaling in this scenario as we want to avoid big chunks of limescale damaging the screen inside the tip.

      21. 0 votes
        Answered by the admin

        This is a single boiler unit with a heat exchanger inside. The heat exchanger does allow on demand steam.

        The Vibiemme double boiler is a different espresso machine model.



      22. 0 votes
        Answered by the admin

        We suggest running a descaler through the grouphead without the blind filter and then with the blind filter to see if the problem resolves. 3 cycles of 30 seconds for each above, then 3 cycles of same for rinse.

        When a pump reaches over 10 bar, we usually consider this normal operating condition, and it is normal for a vibration pump to hum when the pressure gets high. Typically, when pumps fail, they have no pressure at all. Hence, it can be the OPV. Try the descaling and see if there is an improvement. If still an issue after, please email us the purchase information.

      23. 0 votes
        Answered by the admin

        Please review JavaJim's video on solving and correcting this issue for self-repair.

      24. 0 votes
      25. 0 votes
        Answered by the admin

        Sorry, it can be any of those parts, and the machine, at this point would need to be evaluated by a profession, or you can start  with a pump replacement first, then OPV.

        Since you seem to have the electronic model with the 5 push buttons (as this one has the green light) you may also have a bad flowmeter, as well. The only way to determine a correction is by parts replacement as there is no test for the flow meter or the wire or this one.

      26. 0 votes
        Answered by the admin

        The average lifespan of a vibration pump is about 5 years. To test, put in the blind filter into the portafilter, lock the portafilter into the grouphead, and engage the pump by lifting the lever up.

        If it reaches over 8 bar consistently after the initial 10 seconds, then the pump is ok. If not, it could be a bad pump, or the OPV is blocked in the open position, or the grouphead has a blockage. Once these are clear, you can test the pump again with the blind to confirm it is defective.

        AT this point, with the blind, run a descaler with the blind for 30 seconds, then let sit for 20 minutes, then repeat twice. This descaling

      27. 0 votes
        Answered by the admin

        Thank you for selecting 1st-line for your machine. This sounds like the gicleur in the mushroom located in the top of the grouphead is clogged - usually clogs on any E61 grouphead that sits for more than 2 weeks or the water is hardened with magesium or calcium.

        Steam boiler turn off. We suggest running a descaler only for 3 minutes. Let sit for 10 minutes and try again twice. If it clears, then rinse for 3 minutes on and 3 minutes off.

        If this does not work, please review grouphead diagram and then the mushroom needs to be removed and the gicleur needs to be removed and cleaned manually.

      28. 0 votes
        Answered by the admin

        We are sorry to hear about this. Usually, a surge in the electrical current or water can cause this. Sometimes, if the machine is older, this can happen.

        We are sorry to hear about this. The machine would need to be unplugged from the electrical outlet. Then the body panel removed, and finally a multimeter would need to be used to test the different electrical components for the fault. An inspection of all wiring and components is in order, as well.

        We are sorry, but we do not offer any training on multimeter usage. Hence, if one does not have this knowledge, it is better to check with someone who has or hire a professional for the diagnosis and repair.
