Overview
Videos




Features
Grinding Adjustment
- Stepless – Infinite number of grind settings which allows you really fine tune your grind. Adjustment dial is on the right side of the grinder. Turn clockwise for a finer grind and counterclockwise for a coarser grind.
Grinding Operation
- Semi automatic – The power button is on the left side. To start grinding, push your portafilter against the grinding button above the fork. Press and hold for continuous grinding, and release to stop.
Grinding Burrs
- Conical Grinding Burrs – 38 mm in size. Spins at a low rpm which generates less heat. Heat buildup can negatively affect your coffee grinds by heating the coffee grinders before brewing.
Bean Hopper
- Low profile – The total height of the grinder with the hopper is approximately 12″.
Specifications
| Brand | Lelit |
|---|---|
| Height (inches) | 12, approximate |
| Width (inches) | 7, approximate |
| Depth (inches) | 5, approximate |
| Weight (pounds) | 6, approximate |
| Wattage (watts) | 150 |
| Voltage (volts) | 120 |
| Burr size (mm), Type | 38, conical |
| Hopper capacity (grams) | 250 |
| Country of manufacture | Italy |
| Doser | No (doserless) |
| Grinding Adjustment | Stepless |
Notes
Espresso Coffee Grinder Warnings:
- Roast Profiles: Espresso grinders sold by 1st-line Equipment, unless specifically indicated on the grinder page, are manufactured for coffee beans that have Italian or espresso roast profiles. Lighter roasted coffee beans may clog the grinder or not grind fine enough. Darker roasted coffee beans, such as French roasted or oily coffee beans, may clog the grinding chamber and/or the grinder chute where the ground coffee exits.
- Changing grind settings: It is very important to only change grind settings when the unit is powered on and the burrs are in motion. If you do not do this, the burrs will ‘gunk’ up and render the grinder to only produce very coarse grinds or no grinds at all. To remedy this, you will have to open up the grinder to get access to the grinding burrs. This issue will be considered operator error for lack of following directions, and not be classified as a defective grinder.
- Electrical cord: For most grinders, the cord is placed between the packaging (foam or cardboard) and the underside body of the grinder. During shipping, it is normal for a bend or insignificant blemish/slice to damage the cord.
- Finding coffee grinds in a new grinder: Most manufacturers test their grinders with coffee beans before they leave their facility. Unfortunately, they are not always able to get every trace of coffee out of the grinders after testing. As a result, you may find coffee beans or grinds inside your grinder, or there may be grinds in the packaging.
- Static issues: There are static issues with all grinders, even the highest-quality models. We firmly believe that the static comes from the coffee beans. If you are having static problems with your coffee grinder, try using a different blend of beans.
- Electrical: To avoid electrical damage (which is not considered a manufacturer's defect), please acquire and install a single-outlet surge suppressor rated at 1080 joules or higher. A surge without protection can damage a grinder at the power switch, the capacitor, the motor, or the wiring.
- Burr cleaning: For routine maintenance of the grinding burrs, we recommend using grinder cleaning agents. We do not recommend any removal of the burrs or the burr carrier for cleaning (unless necessary) as re-assembly can cause damage. If the grinder chamber is dis-assembled, the warranty is voided for any damages that result. It is important to always remove all coffee grinds from the threads of the burr carrier and the grinding chamber.
- Replacing burrs: NEVER use a flat head screwdriver and hammer to wedge UNDER the burrs for removal. This could badly damage your grinder.
Support
Parts Diagram
- Please use the parts diagrams provided below to determine the part(s) you need. Then use our search box above to find the part(s) on our website.
Note: These parts diagrams are provided by the manufacturers. We list them on our site for informational purposes only. We do not stock every single part listed nor can we guarantee that every part is available to order. - If uncertain, please go to the equipment model or part product page. Then use the Q&A tab found on that web page to ask your question.
- Lastly, and only if the first 2 options were exhausted, please use our parts inquiry page.
- Our call center does not have the training to handle parts inquiries for over 60,000 different parts items. Asking any questions regarding parts will more than likely result in you being referred to the above steps.
- Please note also that all parts purchases are non-returnable or refundable and do not include technical support, instructions, or warranties as the purchase price of any part does not cover the cost of technical support. Technical support is available for repairing equipment in our shop.
- Sorry, we will only special order a part for a model we carry AND was purchased through our supply chain.
- Since we are unaware of the mechanical, electrical, and/or plumbing expertise of a parts buyer or the tools owned by a parts buyer, we are never able to advise if a self-repair can be performed.
| 10000020 | MC304-R01 |
| 7900009 | MC330-110 |
| 8800001 | MC331 |
| 8900030 | MC342-250 |
| 9100030 | MC343G |
| 9600069 | MC346-2 |
| CD361 | MC370 |
| CD377 | MC370-1 |
| CD458 | MC372 |
| CD458-2 | MC375 |
| CD553 | MC376 |
| CD553INOX | MC428 |
| GV025-23 | MC591 |
| GV025-27 | MC784 |
| MC020 | MC785 |
| MC076 | MC786 |
| MC208 | MX129 |
| 1000011 | MC210 |
| 1000020 | MC217 |
| 1400156 | MC221 |
| 1600001 | MC234 |
| 3700010 | MC245 |
| 9100022 | MC248 |
| 9300001 | MC249 |
| AST113 | MC288 |
| CD377 | MC289 |
| CD553INOX | MC290 |
| CVMC246 | MC293 |
| CVMC246-1 | MC311 |
| GV025/46 | MC373 |
| GV565 | MC607 |
