ACS Vesuvius EVO Leva Espresso Machine w/ SS & DCS

Introducing the ACS Vesuvius EVO Leva Espresso Machine: Elevate Your Coffee Experience!

Are you ready to transform your home brewing game? Meet the ACS Vesuvius EVO Leva Espresso Machine—a masterpiece that seamlessly marries advanced technology with artisan craftsmanship. This dual boiler powerhouse invites you to explore the art of espresso extraction like never before.

With its innovative lever extraction system, you’ll have the control and precision to craft that perfect shot of espresso. The tactile feel of the lever not only brings a touch of tradition to your kitchen but also enhances your connection with each cup you create. Every pull is a new opportunity to unleash your inner barista!

The Vesuvius EVO isn’t just about great coffee—it’s packed with cutting-edge features designed for the modern coffee connoisseur. Discover peace of mind with its built-in Safety System (SS) that prevents the lever from snapping back while the machine is fully heated. Plus, the built-in Dosed Coffee System (DCS) automates the end of the extraction so the machine can stop the shot at a predetermined point rather than requiring the barista to manually intervene.

Experience the precision of triple PID controls, allowing you to fine-tune the temperature of the grouphead, coffee boiler, and steam boiler independently. This means you can achieve optimal extraction for every single coffee variety, ensuring that you extract the utmost flavors and aromas from your beans.

Whether you’re a seasoned espresso aficionado or just beginning your coffee journey, the ACS Vesuvius EVO is designed to inspire creativity and elevate your daily ritual. With its sleek design and professional-grade performance, it’s not just a machine – it’s a statement piece that will make your kitchen the envy of every coffee lover.

Indulge yourself in the world of exceptional espresso with the ACS Vesuvius EVO Leva Espresso Machine. Are you ready to elevate your brew? Your perfect cup awaits!

Updated starting October 2024! Built in safety system and built in dosed coffee system.

Coming soon…

• Independent temperature adjustments for group, coffee boiler and steam boiler.
• Pre-infusion pressure adjustment from 1.5 to 5 bars.
• Rapid heating 12 minutes needed to make the first coffee.
• Pressure gauge on the unit to monitor the infusion pressure throughout the extraction arc, intervening at will to increase or decrease the pressure.
• Daily timer
• Touch display for real-time control of all machine parameters.
• Access to the tank from the side panel.
• Double boiler in stainless steel 316L of 0.8L and 2.3 L
• SM Style group with double spring
• Gear pump
• Professional steam power 200 ml in 15 seconds
• Frame and panels entirely in AISI 304
• Switchable between 3 L tank or a direct water line connection.
• Parts & Accecssories included:
  • 3 portafilters handles, Double single and bottomless
  • Double basket, single basket
  • Various Spares
  • 4 felt pads and 4 rubber pads
  • Group cleaning brush
  • Aluminium Tamper

1. All the machines with the safety system already installed, when the user swaps from the safety system to the standard non-safety system, there is no need to have a “separate pin block“ as shown in the manufacturer’s videos. Please simply remove the “separate pin block” from the installed one the safety system and place it on the standard one. The piece is not missing, the manufacturer simply updated that piece. Their video is outdated.

• Upon first use (tank/reservoir models): On the initial start-up (or after a long period of non-use), it is important to make sure the pump is removing water from the tank. When the machine is powered on, you will hear the pump running. After 5 seconds, squeeze the in-line hose in the tank (usually the longest hose, has a particle filter attached). if you hear a different sound, this means the pump is working correctly. If not, immediately power down the machine and contact us. For more information, visit this page General Manual Pump Priming.
• Electrical: To avoid electrical damage to this espresso machine which is not considered a manufacturer's defect, please acquire and install a single-outlet surge suppressor rated at 1080 joules or higher. Without the recommended surge suppressor, the espresso machine can be damaged at the power switch, the electronics, the heating element, the pressurstat, or the wiring inside. For more information, visit this page Power Protection.
• Water: To increase the useful life and not damage your espresso machine, please use softened water. Softened water is water without calcium and magnesium, but still has other minerals for espresso extraction. Do not use distilled, purified, or reverse osmosis water as these types of water create oxidation with the metals and cause the same damaging effects as limescale. For more information, visit this page Water Choice.
• Descaling: We do not recommend descaling unless there is an issue with the espresso machine. Too much descaling can eat away at the metals and gaskets inside an espresso machine. As a preventative measure, we recommend using softened water as explained in the bullet point above.
• Backflushing: Unfortunately this type of espresso machine cannot be backflushed because there is no solenoid valve to relieve built-up pressure in the grouphead. A quick way to clean the grouphead is to lock in your portafilter with no coffee and pull the lever down a few times. The long way is removing the screen, however, this runs the risk of damage.
