Please follow the directions below if the doser lever is not moving the dosing vanes.
- Unplug the grinder.
- Remove beans from bean hopper and ground coffee from doser.
- Lay grinder on side on top of towel and remove the 3 screws from bottom base plate.
- Remove the 2 screws holding the fork and the 2 screws holding bottom doser cover.
- Replace the cam spring and screw. When replacing the teeth disc/flywheel, make sure to keep all other center stem parts in place as it can be difficult to put back.
|
|
|
|
