DISCONTINUED VBM Lollo HX Direct Connect Espresso Machine

This product has been discontinued at 1st-line. Please visit one of the categories below for more comparable products.

.

VBM Lollo HX Direct Connect Espresso Machine

The VBM Lollo espresso machine is a beast!!! VBM’s E64 grouphead is their upgrade to their E61 grouphead that offers a superior extraction.

Features:

  • E64 Kometa grouphead: This chromed-brass electronic thermosiphonic circulation group, with mechanical pre-infusion boiler.
  • Brew pressure gauge on left indicates brew pressure created by pump.
  • Boiler pressure gauge on right side indicates steam pressure created in the boiler.
  • Filter diameter 58 mm.
  • Semi-automatic operation:2 simple buttons. One to start the espresso extraction and one to stop the espresso extraction. Two buttons offer a longer useful life.
  • Heat exchange system: Powerful on demand steam and hot water available during the espresso extraction process.
  • Multi-directional steam & hot water wand allows change in multiple directions.
  • Joystick controls on hot water and steam valves lock in any position for hands free operation.
  • Full size Sirai pressurstat assures years of trouble-free use.
  • Premium Gicar brain unit (auto water boiler refill) is the best in the business.
  • Adjustable water line pressure expansion valve located under removable drip tray cover.
  • Boiler drain access easily accessible from opening on bottom of machine.
  • Built-in Boiler Refill Protection – the machine will shut off the pump and heating element if it takes longer than 120 seconds to refill the boiler. This helps in case someone shuts off the water supply line or there is an impediment in the the water line (i.e. inline hose bent) that prevents from the boiler from properly refilling.
  • Large, 3.5 Liter copper boiler maintain temperature stability as well as structural integrity and lots of steam power for small offices, catering, and small businesses.
  • Rotary vane pump provides consistent pump pressure and can be adjusted.
  • Removable drip tray cover and grate – both made of stainless steel.
  • Cup warmer tray passively heated from heat rising from boiler.
  • Front panel, rear panel, and top cover/cup warmer made of stainless steel. Black steel side panels and frame.
  • Direct water connection: This machine requires a direct water line connection to not only filtered water, but softened water. Softened water is water whereby calcium and magnesium are removed from the water.
  • Four chrome-plated, steel feet are adjustable for those uneven countertops.
  • Non-return steam valves to prevent boiler contamination of milk syphoning back to boiler.
  • High quality, anti-vacuum valve on boiler.
  • Injectors and HX restrictors to improve temperature stability.
  • Large 12mm thermosypon copper pipes from boiler to grouphead.
  • Stainless steel boiler refill probe.
  • Accessories included: Instruction manual, UL sticker, single spout portafilter with single cup basket, dual spout portafilter with double cup filter basket, blind filter basket, 71.25″ reinforced rubber drain hose (assembly onto catch basin required), two stainless steel braided hoses (71″ and 39.75″) for direct water line connection hookup.

Would you like to learn more about our other home espresso machines? Then please review our webpage!


For more VBM equipment, please visit our VBM brands page. If you have any questions, please reference the Q&A tab on each product page.

VBM Lollo HX Direct Connect Espresso Machine

Brand

VBM (Vibiemme)

Height (inches)

22, approximate

Width (inches)

17, approximate

Depth (inches)

24, approximate

Weight (pounds)

78

Wattage (watts)

1600

Voltage (volts)

110

Boiler capacity (liters)

3.5

Portafilter size (mm)

58

Country of manufacture

Milan, Italy

Approvals

UL

Espresso Machine Warning:

  • ELECTRICAL WARNING: To avoid electrical damage to this espresso machine which is not considered a manufacturer's defect, please acquire and install a single-outlet surge suppressor rated at 1080 joules or higher. the lack of the recommended surge suppressor, the espresso machine can be damaged at the power switch, the electronics, the heating element, the pressurstat or the wiring inside.
  • WATER WARNING: To increase the useful life of and not damage your espresso machine, please use softened water. Softened water is water without calcium and without magnesium, but still has other minerals for espresso extraction. Do not use distilled water, purified water, nor reverse osmosis water as these types of water create oxidation with the metals and cause the same damaging effects as limescale.
  • DESCALING WARNING: We do not recommend descaling unless there is an issue with the espresso machine. The reason is that too much descaling can eat away at the metals and gaskets inside an espresso machine.

  1. Tank mode?: This machine is can only operate by hooking up to a water line and drain. There is no tank / reservoir mode.
  2. Shipping: This machine only ships on a pallet to avoid damages that could occur with UPS or FedEx. Hence, expedited shipping is not available for this machine.
  3. Water line connection: Stainless steel braided hose for direct water connection requires a 3/8th BSPT male connection. Adapters are optionally available. Please contact us.
  4. Water line pressure: Should not exceed 45 psi. The manual states 4 bar or approximately 64 psi, but 1st-line recommends a lower pressure.
  5. Drain line: The drain hose needs to vertically drop 1" for every 12" it goes across horizontally.

Customer reviews

Reviews

There are no reviews yet.

Be the first to review “DISCONTINUED VBM Lollo HX Direct Connect Espresso Machine”

Use one of the allowed file type: jpg,png. The max size allowed is : 3 MB.

    This site uses Akismet to reduce spam. Learn how your comment data is processed.

    Ask a question

    Please ask follow up questions as a new question. Submitted questions will be first reviewed, answered, and lastly publicized.

      can you get me a vbm lollo in a 1 group 220 v and if so a price on it . is it the same a the 110 unit and can you get the lollo in a 2 group and if so a price on it as wel
    1. 0 votes
      Q can you get me a vbm lollo in a 1 group 220 v and if so a price on it . is it the same a the 110 ...... Read more answer now
      Asked by Shannon on February 17, 2020 4:31 pm
      Answered by the admin

      Sorry, we only have the single 1 group unit in 110 volts.

    2. how do I connect water line? metric on machine not compatible here in New York!!
    3. 0 votes
      Q how do I connect water line? metric on machine not compatible here in New York!! answer now
      Asked by David on October 17, 2018 12:11 pm
      Answered by the admin

      Please our recommended requirements.

    4. Re: Vibiemme Lollo Commercial Espresso Machine Is the E64 really that much better than the E61 group head?
    5. 0 votes
      Q Re: Vibiemme Lollo Commercial Espresso Machine Is the E64 really that much better than the E61...... Read more answer now
      Asked by John Henson on November 8, 2017 10:51 pm
      Answered by the admin

      Per Vibiemme, they feel the E64 grouphead is more stable in temperature in a commercial enviroment.
