SIDEWALK SALE – ECM S-Automatik 64 Anthracite Espresso Grinder OPEN BOX

ECM S-Automatik 64 Espresso Grinder

The ECM S-Automatik 64 is one of ECM's high end espresso grinders. The stepless wormgear adjustment allows for very fine grind tuning. This allows for easy compatibility with any espresso machine and espresso blend. On demand grinding ensures your coffee is ground fresh every time. The electronic controls adjust the grinding time for single & double dosing.

Grinding adjustment

• Stepless - Gives you access to an "infinite" number of grind settings. This allows you really fine tune your grind fineness of your coffee beans. The numbered dial underneath the hopper helps you remember your current grind setting easier.
• Stainless steel adjustment knob - BOTH the stainless steel and anthracite-colored model have this. Located in the rear of the machine just below the hopper. Turning the knob clockwise will make the grind finer. Turning counterclockwise will make the grind coarser.
• Round worm gear - Stainless steel model has a black, plastic worm gear. The anthracite-colored model has a stainless steel worm gear.

Grinding burrs

• Flat burrs - Large size at 64 mm. The larger the size, the more of a grinding surface, resulting in faster production.
• High rpm - Faster spinning rate at 1400 rpm. The higher the speed, the faster the production, which can increase efficiency and reduce wait times.
• Easy access - Remove the bean hopper & the set screw. There are 3 Allen key screws (~2.3 mm) that hold the upper holder in place. After removing the screws, turn the upper burr holder counter clockwise until the top assembly comes off. This will give you access to the burrs and the grinding chamber. The burrs themselves are held in with 3 flat head screws.

Electronic controls / On demand grinding

• Multiple dosing options - Press the dosing button once for a single dose. Press the dosing button quickly twice for a double dose. Hold the dosing button for a manual dose.
• Time based grinding - You can adjust the the time for each automatic dose. You can make tiny adjustments by 0.1 second increments.
• Dosing count - This helps keep track of usage. Displays the total count of automatic doses, not manual doses. Single doses will add 1 to the tonal count. Double doses will add 2 to the total count.

Bean hopper

• Low profile - There are 2 hoppers available for the ECM S-Automatik 64. We include the shorter hopper with our grinders. The total height of the grinder is approximately 16.5." It should easily fit under standard 18" overhead cabinets.
• Set screw - Secures the hopper to the grinder. Serves as a reminder for users from quickly removing the hopper if it is full of beans.
• Finger guard - Prevents users from "accidentally" putting their fingers in the grinding burrs.
• Stopper - A door near the bottom of the hopper can be pushed in to close the opening. This allows you to remove the hopper with beans inside so you can easily change the beans. There will be some beans already passed in the burrs which you will have to grind out first before removing the hopper.

Portafilter fork

• Ease of use - Accommodates most portafilters. The clearance from the fork to the funnel is approximately 2.25."
• Container grinding - The forks are not easily removable. However the coffee funnel and fork sit high on the grinder. You can fit any small container (under 4.25") underneath the fork.

Grinds catch tray

• Easy to "install" - There are no screws The tray has 2 holes that hook to the front legs of the grinder. This ensures that the tray won't slide away from the grinder.
• Convenient - As easy as it is to install, it’s just as easy to remove to discard any excess grinds. There are other comparable models that do not have a tray at all.

Accessories included

• Instruction manual - Short manual. Access the full manual online.
